2.3 Built-In Compressor and Air Hose Storage

The EverStart Jump Starter features a built-in compressor capable of inflating tires and recreational inflatables up to 120 PSI. The compressor is controlled by a power button and pressure adjustment buttons on the control panel. The air hose and nozzle adapter are neatly stored in a dedicated compartment, ensuring easy access and organization. This feature adds versatility, making the device ideal for both automotive emergencies and outdoor activities.

Safety Precautions and Warnings

Never attempt to jump-start a frozen battery or use improper extension cords, risking fire or electric shock. Always wear protective eyewear and read the manual carefully.

3.1 General Safety Guidelines

Always read and follow all safety instructions in this manual. Wear protective eyewear and avoid using the jump starter near water. Never attempt to jump-start a frozen battery or use improper extension cords, as this can cause fire or electric shock. Keep the unit away from children and ensure proper ventilation. Follow all warnings and guidelines to prevent injury or damage. Use the device only for its intended purpose and as described.

3.2 Risk of Fire, Electric Shock, and Burst Hazard

Never use improper extension cords, as they can cause fire or electric shock. Avoid charging non-lead-acid batteries, as they may burst. Risk of injury exists from battery acid contact, which can cause blindness or severe burns. Always wear protective eyewear and keep water nearby for emergencies. Follow all safety guidelines to prevent accidents and ensure safe operation of the EverStart Jump Starter.

3.4 Protective Eyewear and First Aid Procedures

Always wear protective eyewear when using the EverStart Jump Starter to prevent potential battery acid contact, which can cause severe burns or blindness. In case of acid exposure, immediately flush the affected area with water and seek medical attention. Keep fresh water and soap nearby for emergencies. Failure to follow these procedures may result in serious injury or permanent damage.

Charging and Recharging Instructions

Charge the EverStart Jump Starter fully before first use, ensuring 24 hours of initial charging. Recharge every 30 days when not in use to maintain battery health and performance.

4.1 Initial Charging Requirements

The EverStart Jump Starter must be fully charged before its first use. Connect the built-in 120 Volt AC Charger, ensuring the battery status icon on the LCD screen displays four solid bars. Initial charging should take 24 hours or until the indicator shows a full charge. Failure to fully charge the unit initially can lead to reduced performance and potential battery damage. Always monitor the LCD screen for charging progress and ensure the device is not used during the charging process.

4.2 Routine Maintenance and Recharging

Regular maintenance ensures optimal performance and extends the life of your EverStart Jump Starter. Recharge the unit every 30 days when not in use and after each jump start to prevent deep discharge. Monitor the LCD screen for battery status, with four solid bars indicating a full charge. Ignore low-battery warnings may result in automatic shutdown and reduced performance. Always store the device in a cool, dry place and avoid extreme temperatures to maintain battery health.

4.3 Using the Built-In 120 Volt AC Charger

To charge your EverStart Jump Starter, plug the built-in 120 Volt AC Charger into a standard household outlet. Ensure the unit is turned off during charging. The initial charge requires 24 hours or until the LCD screen shows four solid bars. Avoid using extension cords to prevent overheating. The charger is designed for safe and efficient charging, with built-in protection against overcharge. Always monitor the LCD screen for charging progress and status updates.

Jump Starting a Vehicle

Jump starting a vehicle with the EverStart Jump Starter is a straightforward process. Ensure the unit is fully charged and follow safety guidelines to avoid hazards. Always connect clamps correctly to battery terminals and vehicle frame, avoiding reverse polarity. This ensures safe and effective engine starting for vehicles up to 2.5 liters.

5.1 Step-by-Step Jump Starting Procedure

Step 1: Turn off the engine, lights, and accessories of both vehicles. Engage the parking brake and ensure vehicles do not touch.

Step 2: Set the jump starter to “Jump Start” mode using the mode switch.

Step 3: Connect the positive (red) clamp to the dead battery’s positive terminal.

Step 4: Attach the negative (black) clamp to a grounded metal part on the dead vehicle.

Step 5: Start the working vehicle’s engine and let it run for 1-2 minutes.

Step 6: Attempt to start the dead vehicle’s engine. If it doesn’t start, allow the working vehicle to run for a few more minutes.

Step 7: Once started, remove the clamps in reverse order: negative first, then positive.

5.2 Important Cautions During Jump Starting

Always wear protective eyewear and ensure the area is well-ventilated. Never jump-start a frozen battery, as it may burst. Avoid reverse polarity connections to prevent damage or electric shock. Do not touch clamps to each other or metal surfaces. Ensure the dead vehicle’s battery is lead-acid compatible. If the vehicle has advanced computer systems, consult the owner’s manual before jump-starting. Keep the jump starter away from open flames or sparks.

5.3 Troubleshooting Common Jump Start Issues

If the jump starter fails to start the vehicle, ensure clamps are securely connected to correct terminals. Check the battery status on the LCD screen; a low charge may require recharging. Verify polarity connections to avoid reverse hookup. If error messages appear, consult the manual for specific fault codes. If issues persist, reset the unit or allow it to cool down before retrying. Always refer to the troubleshooting guide for detailed solutions.

Using the Built-In Compressor

The EverStart Jump Starter features a built-in compressor for inflating tires and recreational inflatables. Use the Compressor Power Button to activate and adjust pressure with the control buttons. Always monitor pressure on the LCD screen to avoid over-inflation. Store the air hose securely after use. Ensure the compressor is turned off when not in operation for safety and efficiency.

6.1 Compressor Power Button and Pressure Control

The Compressor Power Button activates the built-in compressor for inflating tires and inflatables. Use the Increase (+) and Decrease (-) buttons to adjust pressure, visible on the LCD screen. The compressor operates up to 120 PSI. Always monitor pressure to avoid over-inflation. Ensure the compressor is turned off when not in use. Proper pressure control prevents damage to tires and ensures safety during operation.

6.2 Inflating Tires and Recreational Inflatables

The EverStart Jump Starter’s compressor is designed to inflate tires and recreational inflatables safely and efficiently. Attach the Sure Fit nozzle to the hose and set the desired pressure using the control buttons. For tires, ensure the valve stem is upright and secure before inflating. For inflatables, check the recommended pressure to avoid over-inflation. Always monitor pressure during use and turn off the compressor when finished to conserve battery life and maintain safety.

6.3 Compressor Safety and Maintenance Tips

Always follow compressor safety guidelines to prevent damage or injury. Regularly inspect hoses for cracks and nozzles for blockages. Avoid over-inflation, as it can lead to bursting. Store the compressor in a dry, cool place when not in use to prevent rust. Clean the compressor to remove dirt and debris. Allow it to cool down between uses to avoid overheating and extend its lifespan. Refer to the manual for detailed maintenance instructions to ensure optimal performance and longevity.

USB Power and Fault Protection

The USB ports provide 2.1A (5V each) for charging devices. Fault conditions like low voltage, overload, or short circuits trigger automatic shutdown to protect connected devices and the unit.

7.1 USB Port Features and Power Output

The EverStart Jump Starter features dual USB ports delivering a combined 2.1A (5V each) for charging small devices. These ports provide power to external USB-powered devices but do not support data communication. Each port is designed to handle individual devices within the 5V specification. If a fault occurs, the ports automatically shut down to protect connected devices. Ensure devices do not exceed the total 2.1A output to maintain safe and efficient charging. This feature is ideal for charging smartphones, tablets, and other compatible accessories while on the go.

7.2 Fault Conditions and Automatic Shutdown

The USB ports monitor for faults such as low battery voltage, overload, and short circuits. If a fault occurs, the Fault Icon flashes on the LCD screen, and the ports automatically shut down. Disconnect the device, press the USB Power Button to reset, and ensure the unit is fully charged. If the issue persists, check for device malfunctions. Allow the unit to cool before retrying to prevent damage.

7.3 Troubleshooting USB-Related Issues

If USB devices malfunction, check compatibility and ensure total power draw does not exceed 2.1A. Disconnect faulty devices, press the USB Power Button to reset, and verify the unit is charged. If issues persist, allow the unit to cool and retry. For unresolved problems, consult the manual or contact customer support for assistance. Ensure devices meet specifications to avoid recurring faults and maintain optimal performance.

LED Area Light and LCD Screen

The LED Area Light activates with a beep, illuminating work areas. The LCD screen displays battery status, voltage, and fault indicators, ensuring real-time monitoring and automatic low-voltage shutdown.

8.1 Activating and Using the LED Area Light

Press the Area Light Power Button to activate the LED light, which emits a beep on startup. The backlit LCD screen illuminates for 10 seconds, then displays the battery status. The LED provides reliable illumination for nighttime or low-light conditions. Always turn off the light when not in use or during charging to conserve battery life. This feature ensures visibility while working on vehicles or inflatables, enhancing safety and convenience.

8.2 Understanding the LCD Screen Indicators

The LCD screen displays essential information, including the Battery Status Icon, Battery Voltage Indicator, and function-specific icons like the Compressor Icon. The Battery Status Icon shows charge levels with up to four bars, while the Battery Voltage Indicator provides precise voltage readings. Other indicators, such as the Fault Icon, alert you to issues like low battery or overload. Monitoring these indicators helps ensure safe and efficient operation of your EverStart Jump Starter.

8.3 Battery Status and Low Voltage Protection

The EverStart Jump Starter features a Battery Status Icon on the LCD screen, indicating charge levels with up to four solid bars. When the battery is nearly empty, the icon flashes, and the unit automatically shuts down to prevent damage. Low voltage protection ensures the battery isn’t over-drained, preserving its lifespan. Always recharge the unit when the battery level is low to maintain performance and avoid permanent damage.

Downloading the EverStart Jump Starter Manual

Access the EverStart Jump Starter manual by locating your model number and downloading the PDF online. Save and print it for easy reference and future use.
